Two Component Glue Mixer Ab Glue Mixing Dispenser Manual Pressure Barrel Dispensing Machine

Brand Name : D&H

Model Number : PJL-1200

Certification : CE

Place of Origin : CHINA

MOQ : 1

Price : 4999

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Delivery Time : 10 Work Days

Packaging Details : Wooden Box Packing for Sea Shipment

Model NO. : automatic glue dispenser

Driven Type : Electric

Flow Rate : 20-1,000 G/Min

Mixing Range : 1:1 to 1:10

Mixing System : Static or Dynamic

Viscosity : Max 40000cps

Work Area : 480*480 to 2500*480mm

Max Moving Speed : 500mm/Sec

Input Air Pressure : 0.5MPa-07MPa

Control System : PLC Control

Ratio Control : Gear /Screw/ Double Cylinder Pump

Tank Volume : 10L.25L.40L Optionl

Gluing Speed : 1-12ml/S

Transport Package : Wooden Packing

Trademark : D&H

Origin : China

HS Code : 8424899990

Supply Ability : 50PCS Per Month

Precision : High Precision

Condition : New

Warranty : 12 Months

Automatic Grade : Semiautomatic

Installation : Vertical

Customization : Available | Customized Request

Contact Now

Overview:

Potting and encapsulation involve embedding products in liquid resin to protect them from environmental damage, including corrosion and vibrations. We provide automated and semi-automated fluid dispensing machines for potting, including 2-component and epoxy dispensing systems and related vacuum systems. Our equipment includes high-precision dispensing valves, automated glue dispensers, and glue mixing machines, designed for electronics production.

Two Component Glue Mixer Ab Glue Mixing Dispenser Manual Pressure Barrel Dispensing Machine

Applications:

Industry: Capacitor, power supply, transformer, ignition coil, reverse sensor, circuit board, electronic ballast, other electronic products, and LED products where glue potting is demanded.

Two Component Glue Mixer Ab Glue Mixing Dispenser Manual Pressure Barrel Dispensing Machine

Glue:
Epoxy, silica gel, AB glue, PU, and other glue that need matching

Optional Function:
1, Evacuation
2, Heating
3, Geared pump & plunger piston pump are available; Customers can choose to needs.
4, Control will be chosen to be added to the program to needs.

ITEM	Parameter
Mixing ratio	1:1--10:1 adjustable
Size	205012502500mm
Displacement speed	300mm/s(speed)
Operation mode	Manual/Auto
Accuracy	±4%(output volume)±2%(mixing)
Pump	Optional
Flow control	Digital input
Program memory	99pcs-999pcs
Motion trail	Dot, line, curve, circle
Automatic controlling system	PLC/ Touch screen (to achieve program programming, modification, storage, and so on)
Out-glue control system	AB glue back suction valve, achieve AB glue independent operation
Programmatically	Tech programming/or computer systems (Micro software Windows 7, Windows10 optional)
Mixing method	Static/ Dynamic mixing
Power supply	220V/50Hz/1500W without heating
Air source	0.5-0.7Mpa
Viscosity range	1-20000cps
A tank	10L 25L 40L stainless tank(optional)
B tank	10L 25L 40L stainless tank(optional)
Others	AB tank, A pump, AB pipeline heating function

Customization:

Daheng Automation specializes in potting and dispensing systems for various resin applications, including 1- and 2-component polyurethanes, epoxies, silicones, and more. We provide solutions for potting and encapsulation to protect products from harsh environments, including vacuum and atmosphere pressure options. Our offerings include automatic and semi-automatic fluid dispensing machines, dual-component systems, and high-precision dispensing robots. We have the right equipment for adhesive, epoxy, or silicone applications to meet your needs.

D&H accepts a variety of customizations including size, number of tanks, temperature control, etc.

Please contact us for more information!
