Electric Driven Automatic Glue Dispenser for Flow Speed or Customized Applications

Brand Name : D&H

Model Number : PGB-700

Certification : CCC, CE

Place of Origin : MADE IN CHINA

MOQ : 1 Unit

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5-8 Working days

Delivery Time : 5-8 Working days

Packaging Details : 155X135X170 CM

Model NO. : pgb700

Installation : Vertical

Driven Type : Electric

Glue & Ratio : 1:1 to 20:1, Epoxy, Silicone, PU, UV

Certificate : CE, SGS

Xyz Working Area : 700*700*80mm

Flow Speed : 0-66g/5s, or Customized

Additional Function : Heating, Vacuum, Self-Refilling, Self-Cleaning

Transport Package : Wood Box

Specification : 1500x1200x1500mm

Trademark : DH

Origin : China

After-sales Service : One Year

Precision : High Precision

Condition : New

Warranty : 12 Months

Automatic Grade : Automatic

Customization : Available | Customized Request

Contact Now

2K PUR resin compound resin silicone epoxy metering mixing machine 2 part potting machine

We Daheng Automation specialize in different types of potting and dispensing system. No matter what your resin application requirements look like: we can do most of them in our fully equipped lab. We can handle 1- and 2-component polyurethanes, epoxies, acrylics, silicones, temperature, humidity and UV curing materials. They can be from low- to high-viscosity, filled or unfilled
and even high abrasive for thermal conductivity.

Potting and encapsulation is the process of embedding electronic components & assemblies in a liquid resin (potting compounds) toprotect them against rough environment conditions. Potting can be performed in atmosphere pressure or even under vacuum, if high voltage insulation and high temperature differences are needed. Encapsulation of parts will stop corrosion of metals and reduce damage caused by vibration and mechanical stress.

We offer automatic and se-mi automatic fluid dispensing potting machine AB glue dispensing machine Epoxy dispensing machine Two-component dispensing machine Dual-component dispensing machine Meter-mix
dispensing machine Resin dispensing machine Adhesive dispensing system Dispensing robot Dispensing valve Liquid dispenser Automated dispensing equipment

Electric Driven Automatic Glue Dispenser for Flow Speed or Customized Applications
1. Vacuum material-feedingsystem or diaphragm pump feeding system
2. High precision pump metering system
3. Dynamic/Static mixing system
4. Three-axis motion system
5. Programming control system.
Are you tired of manually mixing and dispensing two-component glue solutions? Do you want
to improve the accuracy and efficiency of your production process? Look no further than the AB meter mix machine or the two-component glue dispensing machine!

These machines offer a range of benefits for businesses in various industries. First and foremost, they allow for precise mixing of two-component adhesives, eliminating the need for manual mixing and reducing the risk of human error. This ensures consistent quality in your products and reduces waste, saving you time and money in the long run.

In addition, the machines are designed for easy operation and maintenance, with user-friendly interfaces and accessible components. This means that even operators without extensive technical knowledge can use and maintain the machines with ease.

Moreover, the machines come in a variety of sizes and configurations, making them suitable for various production volumes and adhesive types. Whether you need a small machine for occasional use or a large machine for continuous production, there's an AB meter mix machine or two-component glue dispensing machine to fit your needs.

Finally, these machines can also improve workplace safety. By automating the mixing and dispensing process, they reduce the risk
of operator exposure to potentially hazardous chemicals. This ensures a safer working environment for your employees and reduces
the risk of workplace accidents.

In conclusion, the AB meter mix machine and the two-component glue dispensing machine are powerful tools for improving the accuracy, efficiency, and safety of your production process. By investing in one of these machines, you can reduce waste, improve product quality, and streamline your operations. So why wait? Start exploring your options today and take your production process to the next level!
ITEM Parameter
Mixing ratio 1:1--10:1 adjustable
Working range 700*700*100mm
Displacement speed 250mm/s(speed)
Out-glue speed 1-24g/s(base on the glue ratio)
Accuracy ±2%(output volume)±2%(mixing)
tolerance ≤0.2mm
Flow control Digital input
Program memory 99pcs
Motion trail Dot , line ,curve ,circle
Automatic controlling system Touch screen (to achieve program programming, modification, storage and so on
Out-glue control system AB glue back suction valve, achieve AB glue independent operation
programmatically Tech programming
Mixing method dynamic mixing
Power supply 220V/50Hz/1500W
Air source 0.5-0.8Mpa
Viscosity range 50-20000cps
Outer dimension 1500L*1200W*1600H mm
A tank 25L stainless tank(optional)
B tank 10L stainless tank(optional)
Others AB tank ,A pump,AB pipeline heating function

Application:
Electric Driven Automatic Glue Dispenser for Flow Speed or Customized Applications
1.Potting&Encapsulation &Casting: electronics componnets , PCB board, Capacitor, power supply, transformer, ignition coil, reverse sensor, circuit board, filter products ,underwater parts, electronic ballast ,aviation parts, aerospace parts.... 2.Dispensing&Dosing : LED strip , led lamp , led bulb , aluminum,led screen , display module ,medical parts,medical liquid filling .... 3.Bonding&doming : LCD screen ,LOCA bonding,ABS plastic,different types of stickers , badge , keychains , souvenirs ,arts , photo frame , and other arts graphics....


Applicable Materials :

1K and 2-component polyurethanes, epoxies, acrylics, silicones, temperature, humidity and UV curing materials. Two component potting materials , 2-part compound materials, AB part compound materials , 2K silicones ,2K epoxies resin, Bi-component PU, Ployerster, Polyurethane, UV materials and so on .


Certificate :
Electric Driven Automatic Glue Dispenser for Flow Speed or Customized Applications
Service term

1, Staff training Seller is responsible to provide machine's training including installation, debugging, maintenance to assured customer can totally use the operation skills and well acknowledge maintenance of machine .
2,Maintenance Service 2.1Seller provide one year warranty period and support free maintenance service during warranty . Software upgrade service is provided for a long life time.
2.2 In case parts of the machine become broken within the warranty because of non-artificial factors, we send you part replacement free, buyer pay for the shipment. Double-liquid valve should be bought at its cost price.
2.3If the parts of the machine become broken past warranty , the parts replacement should be shouldered by buyer.
