Working process :
1. Quantify metering system with high precision(±1-2%), suitable for middle to low viscosity two component material ratio .
2. Adapting foreign technology that further improved sealing position and metering in good accuracy.
3. Graphite sealing components ; stainless pump ; stainless connector ensure the pump with long lifespan and anti corruption .
4. Metering pump have Daheng high pressure and high precision double liquid valve , with vary sealing methods and adjustable retract function, that is convenient for glue valve cleaning and precision glue dispensing .
5. Controlling system can program resin dispensing in high precision and reserved many glue dispensing programs .
6. Inset self-check controlling system module makes fault detection rapidly .
7. Through different collections of metering pumps realize the changeable ratio from 1:1 to 10:1 .
8. Keep steady dispensing design , the glue-amount can be adjusted from 0.5g/s~12g/s per single pump, ab pump dispensing amount can be set accordingly to ab ratio .
9.Double cylinder plunger pump's structure especially suitable for high additive ,high density materials . The lifespan is designed for 10 years . Valve technology :
1.The mixing motor drive the blade to stir the glue evenly. The mixing process totally seal ; the double liquid valve and mixing pipe filled with glue that assured glue mixing without any air bubble;the valve through turn on-off the air-cylinder to keep glue suck well and prevent glue from dropping .
2. Stirring motor speed is 2000r/m, which can fully stir glue evenly.
3. Mixing pipe is consumable that from Sulzer Mixpac MR13-12; as per machine downtime , the mixers should be cleaned or soaked in cleaning fluid.
4.Dynamic mixing with stirring detecting function(optional) that ensure glue mixing evenly .
5. Stainless design of the glue touch surface to capture more higher material compatibility .
6.Glue valve with flow-back prevent function that can prevent mixture from dropping when stop dispensing .
7. Sealing parts of rod shaft adopt imported parts to keep more higher durability .
8. The self-cleaning function make machine cleaning more easier that you needn't dis-assembly the parts to wash . Cleaning time and cleaning times could be set in the touch screen. Application:
Potting&Encapsulation &Casting: electronics components , PCB board, Capacitor, power supply, transformer, ignition coil, reverse sensor, circuit board, ,underwater parts, electronic ballast ,aviation parts, aerospace...
Transformer , capacitance , power module , regulating plate ,protection module , generator , pressure package , soli relay ,fault indicator , Sensors , junction box , clutch , wave filter , water meter , battery cover , rectifier and so on ...
Applicable Materials
2-component polyurethanes, epoxies, acrylics, silicones, temperature, humidity and UV curing materials.
Two component potting materials , 2-part compound materials, AB part compound materials , 2K silicones ,2K epoxies resin, Bi-component PU, Ployerster, Polyurethane, UV materials and so on .
